Device length and width

Length: 2500mm Width: 1700mm

bag type

Various film bags such as aluminum foil bags, paper

bags, nylon bags, etc.

bag size

Length: 60-180mm Width: 55-130mm

Filling range

10-1500g

packing speed

45-60 packs/min (the speed is determined by the product

 itself and the filling weight)

Packaging accuracy

Average precision≤+1%

total power

10Kw

Scope of application

Mustard shreds, mustard slices, sour beans, soy products,

pickled vegetables, enoki mushrooms, kelp shreds, etc.,

are measured and weighed.

Scattered dried tofu, pickled vegetables, duck tongue,

dried egg, dried tea, large pieces of dried tofu, chicken

popcorn, spicy chicken nuggets, chicken joints, chicken

thighs, chicken necks, chicken feet, duck gizzards, duck

feet, duck legs, wing roots , wing tips, marinated eggs,

middle wings, two-section wings, three-section wings

and other irregular materials

Optional package

Material weighing and filling machine, working platform,

weight sorting scale, material hoist, finished product

conveying hoist, metal detector

Measurement method

Multi-head computer combination scale, screw scale,

filling machine, shrink cup

work process

Loading the bag→printing the production date→opening

the bag→cutting 1→cutting 2→reservation→heat

sealing→shaping and output
